WPHY 52 Carbon Steel Cross Fitting

Get a Price/Quote

WPHY 52 Carbon Steel Cross Fitting Specification

Flexibility
Rigid

Temperature Range
-20C to 120C

Diameter
As per Specification

Sealing Type
Metal to Metal

Coating Type
Epoxy / Black Paint

Connection Type
Welded

Yield Strength
415 MPa (Min)

Tolerance
0.5 mm

Tensile Strength
520 MPa (Min)

Product Type
Cross Fitting

Material
Carbon Steel

Connection
Butt Weld

Shape
Cross

Standard
ASTM A860

Surface Treatment
Black Painted / Anti-rust Oil

Outer Diameter
1/2 inch to 48 inch (DN15DN1200)

Section Shape
Circular

Length
Customizable as per Requirement

Thickness
5 mm - 20 mm

Color
Black

Usage
Pipeline Industry

Rated Pressure
Sch 10 to Sch 160

Application
Oil & Gas, Petrochemical, Power Plants

Material Grade
WPHY 52

Packaging
Wooden Cases or Pallets

Inspection
100% Hydraulic Pressure Tested

Corrosion Resistance
High

Impact Value
27 J

Manufacturing Process
Hot Formed

Weight
Variable Depending on Size

End Type
Plain End / Beveled End

Stock Availability
Ready Stock

About WPHY 52 Carbon Steel Cross Fitting

Pipe cross manufacturers in India

Standard: ANSI B16.9 / 16.28, ASTM A53/A106, API 5L, ASME B36.10M1996, DIN2605 / 2615 / 2616, JIS P2311/2312
Thickness: SGP, STD, SCH40, SCH80, SCH160. XS, XXS and so on.
Size: 1/260
Material: Carbon steel , alloy steel, stainless steel
Surface treatment: Transparent oil, rust-proof black oil or hot galvanized.

Seamless cross
Erw cross
pipe cross
carbon steel cross

Grade Specification: Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A860 WPHY 42 Pipe Fittings Manufacturers

WPHY 52 equivalent
A860 WPHY 52	A860 Grade WPHY 52 Fittings
A694 WPHY 52	A694 Grade F52 Flanges
A234 WPHY 52	A234 Grade WPB Carbon Steel Fittings A234 AISI 4130 High Strength Low Alloyed Steel Fittings

Grade Specification	Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A420 WPL6
WPHY 52 Fittings Size	Seamless:from 1/2 to 24
WPHY 52 Fittings Size	Welded:from 24 to 96 (or as customer requirements)
WPHY 52 Fittings Degree	22.5 deg, 30deg,45 deg,90 deg,180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D,4D,5D,6D,7D-40D.
WPHY 52 Fittings Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH80., SCH100, SCH120, SCH140, SCH160, XXS
Standard	ASME B16.9, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO
Carbon Steel Material	Carbon steel (ASTM A234 WPB, A234WPC, A420 WPL6, etc)
	Stainless steel (ASTM A403 WP304, 304L, 316, 316L, 321,etc)
	Alloy steel (ASTM A234 WP12, WP11, WP22, WP5, WP9, WP91, etc)
WPHY 52 Fittings Type	Seamless / Welded / Fabricated
WPHY 52 Fittings Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
WPHY 52 Fittings Range	NB to 48 NB in Sch 10s, 40s, 80s, 160s, XXS. From 1/2 to 30 (Seamless Pipe Fittings), Form16 to 100 (Seam Pipe Fittings)
Dimensions	ANSI/ASME B16.9, B16.28, MSS-SP-43.
Testing	Direct reading spectrometer, Mechanical testing, Super living inspection, Magnetic particle inspection, etc

Surface treatment	Sand Rolling, Sand Blasting ,Acid Cleaning
Applicable Standards	1-ASME B 16.9 for large Bore 2-ASME B 16.11 for small Bore (socket welded) 3-ASME B 16.25 for butt weld ends 4-ASME B 16.28 for small radius elbow
Seamless/ Welded 100% Radiography Tested

Note
Other Grade Available	A-350 LF2, ASTM B-333
OTHER FORMS	Compression Fitting / Instrumentation / Hydraulic Fitting / & Also As Per Drawing
Test Certificate	Manufacturer Test Certificate / IBR Test Certificate (Form III-C), Under Third Party Inspection & with Excise Gate Pass to avail Modvat benefit.
Specialize	Long Bend with Radius R = 3D, 5D & 10D Pigabble Bend & IBR Fittings

Standard	Description
ASTM A182/A182M	Forged or rolled alloy steel pipe flanges, forged fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASTM A403/A403M	Wrought austenitic stainless steel piping fittings.
ASTM A815/A815M	Wrought ferritic, ferritic/austenitic and martensitic stainless steel piping fittings.
AS 2129	Flanges for pipes, valves and fittings
ANSI/ASME B1.20.1	Pipe threads, general purpose (inch).
ANSI B16.5	Steel pipe flanges and flanged fittings.
ANSI B16.9	Factory-made wrought steel butt-welding fittings.
ANSI B16.11	Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings
ANSI B16.25	Butt-welding ends.
MSS SP43	Wrought stainless steel butt-welding fittings. Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
BS21	Threading.
ISO 4144	Stainless steel fittings threaded to ISO 7-1.
MSS SP-95	Swage(d) Nipples and Bull Plugs
BS3799	Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
ANSI B 16.9 ASTM A403 ASME SA403	Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
API 590-605 ASME B16.9	Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends
ASME B16.28	Wrought Steel Buttwelding Short Radius Elbows and Returns

Engineered for Demanding Applications

WPHY 52 Carbon Steel Cross Fittings are tailored for mission-critical projects in oil & gas, petrochemical, and power generation. Their corrosion-resistant properties and superior mechanical strength provide enduring connections within complex pipeline networks, even under extreme temperatures and pressures.

Precision Manufacturing & Stringent Testing

Each fitting is hot-formed and produced under rigorous quality control, meeting ASTM A860 standards. A 100% hydraulic pressure test guarantees leak-proof performance, while tolerance accuracy of 0.5 mm ensures a precise fit. Customizable dimensions and coatings meet project-specific requirements.

Flexible & Secure Connectivity

The cross-shaped fittings have butt-welded ends-plain or beveled-for secure, metal-to-metal sealing. Available in various wall thicknesses and diameters, they work efficiently in pipelines requiring rigid, reliable branching. Epoxy and black painted coatings further enhance resistance to external elements.

FAQ's of WPHY 52 Carbon Steel Cross Fitting:

Q: How are WPHY 52 Carbon Steel Cross Fittings typically used in industry?

A: These fittings are primarily utilized to connect four pipeline sections intersecting at right angles, commonly in oil & gas, petrochemical plants, and power plants. Their robust construction and corrosion resistance make them suitable for transporting fluids under high pressure and challenging environments.

Q: What process is used to manufacture WPHY 52 Carbon Steel Cross Fittings?

A: They are produced using a hot-forming technique, which enhances their mechanical properties and ensures structural integrity. Each fitting is subjected to 100% hydraulic pressure testing to guarantee leak resistance and safety in demanding pipeline applications.

Q: When should a plain end be selected over a beveled end?

A: Plain ends are ideal when simple welded connections are needed, while beveled ends are preferred when precise, full-penetration welding is required for high-integrity or high-pressure systems. The choice depends on assembly specifications and joining methods used in your project.

Q: Where are WPHY 52 cross fittings available for purchase and what packaging is offered?

A: These fittings are distributed, exported, and supplied across India by authorized manufacturers and traders. They are packed securely in wooden cases or pallets to ensure damage-free delivery, and ready stock is generally available for prompt dispatch.

Q: How does the high corrosion resistance benefit the pipeline system?

A: High corrosion resistance ensures the cross fitting maintains its structural integrity and tight seals over time, even in harsh or corrosive environments. This reduces maintenance, prolongs service life, and contributes to safer, more reliable operations.

Q: What standards and testing certifications are met by these fittings?

A: WPHY 52 Carbon Steel Cross Fittings conform to ASTM A860 standards and undergo comprehensive 100% hydraulic pressure testing. This rigorous quality assurance ensures consistent product performance and compliance with industry requirements.
