WPHY 52 Carbon Steel Lateral

Get a Price/Quote

WPHY 52 Carbon Steel Lateral Specification

Diameter
Up to 1219 mm

Tensile Strength
520 MPa (min)

Flexibility
Rigid

Bend Radius
Custom as per design

Temperature Range
-46C to 600C

Coating Type
Anti-Corrosion Coating

Sealing Type
Metal to Metal

Tolerance
0.5 mm

Yield Strength
360 MPa (min)

Connection Type
Welded

Product Type
Lateral Pipe Fitting

Material
Carbon Steel

Connection
Butt Weld

Shape
Lateral (Y-Type)

Standard
ASTM A860 MSS SP 75

Surface Treatment
Black Painted / Anti-Rust Oil Coated

Outer Diameter
1/2 48 (DN15 DN1200)

Section Shape
Round

Length
Custom as per requirement

Thickness
Sch 10 Sch 160 / STD / XS / XXS

Color
Black

Usage
Pipeline, Oil & Gas, Petrochemical

Rated Pressure
Up to 20 MPa

Application
Pipeline Systems

Material Grade
WPHY 52

Hardness
220 HBW

Corrosion Resistance
High (with coating)

Marking
Standard Marking on Body

Package
Wooden Cases, Pallets, or As Per Customer

Inspection
100% Radiography and Hydro-Tested

End Type
Beveled Ends (for Butt Welding)

Density
7.85 g/cm

Impact Test Temperature
-46C (Charpy V-Notch)

Manufacturing Process
Hot Forming / Forged

About WPHY 52 Carbon Steel Lateral

OUR EXPORT MARKET: Dubai, UAE, Malaysia, South Africa, Iran, Singapore, Canada, Colombia
TEST CERTIFICATE
Mill Test Certificate as per EN 10204 / 3.1B
Lateral tee pipe fitting manufacturers, reducing lateral tee dimensions
Grade Specification: Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A860 WPHY 42 Pipe Fittings Manufacturers, asme b16.9 lateral tee manufacturer, 45 degree lateral pipe fitting manufacturers

WPHY 52 equivalent
A860 WPHY 52	A860 Grade WPHY 52 Fittings
A694 WPHY 52	A694 Grade F52 Flanges
A234 WPHY 52	A234 Grade WPB Carbon Steel Fittings A234 AISI 4130 High Strength Low Alloyed Steel Fittings

Grade Specification	Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A420 WPL6
WPHY 52 Fittings Size	Seamless:from 1/2 to 24
WPHY 52 Fittings Size	Welded:from 24 to 96 (or as customer requirements)
WPHY 52 Fittings Degree	22.5 deg, 30deg,45 deg,90 deg,180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D,4D,5D,6D,7D-40D.
WPHY 52 Fittings Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH80., SCH100, SCH120, SCH140, SCH160, XXS
Standard	ASME B16.9, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO
Carbon Steel Material	Carbon steel (ASTM A234 WPB, A234WPC, A420 WPL6, etc)
	Stainless steel (ASTM A403 WP304, 304L, 316, 316L, 321,etc)
	Alloy steel (ASTM A234 WP12, WP11, WP22, WP5, WP9, WP91, etc)
WPHY 52 Fittings Type	Seamless / Welded / Fabricated
WPHY 52 Fittings Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
WPHY 52 Fittings Range	NB to 48 NB in Sch 10s, 40s, 80s, 160s, XXS. From 1/2 to 30 (Seamless Pipe Fittings), Form16 to 100 (Seam Pipe Fittings)
Dimensions	ANSI/ASME B16.9, B16.28, MSS-SP-43.
Testing	Direct reading spectrometer, Mechanical testing, Super living inspection, Magnetic particle inspection, etc

Surface treatment	Sand Rolling, Sand Blasting ,Acid Cleaning
Applicable Standards	1-ASME B 16.9 for large Bore 2-ASME B 16.11 for small Bore (socket welded) 3-ASME B 16.25 for butt weld ends 4-ASME B 16.28 for small radius elbow
Seamless/ Welded 100% Radiography Tested

Note
Other Grade Available	A-350 LF2, ASTM B-333
OTHER FORMS	Compression Fitting / Instrumentation / Hydraulic Fitting / & Also As Per Drawing
Test Certificate	Manufacturer Test Certificate / IBR Test Certificate (Form III-C), Under Third Party Inspection & with Excise Gate Pass to avail Modvat benefit.
Specialize	Long Bend with Radius R = 3D, 5D & 10D Pigabble Bend & IBR Fittings

Standard	Description
ASTM A182/A182M	Forged or rolled alloy steel pipe flanges, forged fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASTM A403/A403M	Wrought austenitic stainless steel piping fittings.
ASTM A815/A815M	Wrought ferritic, ferritic/austenitic and martensitic stainless steel piping fittings.
AS 2129	Flanges for pipes, valves and fittings
ANSI/ASME B1.20.1	Pipe threads, general purpose (inch).
ANSI B16.5	Steel pipe flanges and flanged fittings.
ANSI B16.9	Factory-made wrought steel butt-welding fittings.
ANSI B16.11	Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings
ANSI B16.25	Butt-welding ends.
MSS SP43	Wrought stainless steel butt-welding fittings. Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
BS21	Threading.
ISO 4144	Stainless steel fittings threaded to ISO 7-1.
MSS SP-95	Swage(d) Nipples and Bull Plugs
BS3799	Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
ANSI B 16.9 ASTM A403 ASME SA403	Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
API 590-605 ASME B16.9	Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends
ASME B16.28	Wrought Steel Buttwelding Short Radius Elbows and Returns

Precision Engineering for Critical Pipeline Applications

WPHY 52 Carbon Steel Laterals are engineered to deliver strength, durability, and reliable performance in harsh environments. Manufactured using advanced hot forming or forging processes, and coated for optimal anti-corrosion properties, these fittings are designed to withstand pressures up to 20 MPa and temperatures ranging from -46C to 600C. Their precise tolerances and high-quality finish cater to pipeline, oil & gas, and petrochemical needs worldwide.

Thorough Inspection and Testing for Assured Quality

Every WPHY 52 lateral undergoes stringent testing procedures, including 100% radiography and hydrostatic pressure tests. This thorough quality inspection ensures each fitting is structurally sound and leak-proof, adhering to both international standards and customer-specific requirements. Markings for traceability and protective surface treatments further guarantee readiness for demanding applications.

FAQ's of WPHY 52 Carbon Steel Lateral:

Q: How is the WPHY 52 Carbon Steel Lateral manufactured?

A: The WPHY 52 Carbon Steel Lateral is produced through a combination of hot forming or forging processes. These methods ensure the component achieves the required mechanical properties and consistent dimensional tolerances, making it suitable for high-pressure and temperature applications.

Q: What makes these laterals suitable for corrosive environments?

A: To ensure high corrosion resistance, each lateral is coated with either black paint or anti-rust oil. Additionally, an anti-corrosion protective layer is applied, allowing installation in challenging operational conditions such as oil & gas and petrochemical pipeline systems.

Q: When should I use a WPHY 52 Carbon Steel Lateral in pipeline systems?

A: These laterals are ideal for use when you need to direct flow at an angle within the pipeline, especially in complex routing where Y-type connections are required. They are best suited for applications demanding high strength, durability, and resistance to both pressure and temperature extremes.

Q: Where are WPHY 52 Laterals commonly utilized?

A: WPHY 52 Carbon Steel Laterals are commonly used in oil & gas, petrochemical, and various pipeline infrastructure projects. Their robust construction makes them ideal for both above-ground and buried pipeline systems handling fluids under high pressure.

Q: What inspection and testing are performed on these fittings?

A: Each fitting undergoes comprehensive testing, including 100% radiography and hydrostatic evaluations. These inspections guarantee the product's structural integrity, leak-tightness, and compliance with industry standards such as ASTM A860 MSS SP 75.

Q: How does the beveled end design benefit butt welding applications?

A: The beveled end design enables seamless alignment and strong weld joints, facilitating optimal metal-to-metal sealing and minimizing stress concentrations at the joint. This design is particularly advantageous for pipeline installations requiring long-term reliability.
