WPHY 60 Carbon Steel Lateral

Get a Price/Quote

WPHY 60 Carbon Steel Lateral Specification

Tensile Strength
415 MPa min

Coating Type
Epoxy Coated / Black Paint

Temperature Range
-45C to 600C

Yield Strength
290 MPa min

Tolerance
0.5mm

Bend Radius
As per standard

Connection Type
Butt Weld

Diameter
DN15-DN1200

Flexibility
Rigid

Sealing Type
Metal-to-Metal

Product Type
Carbon Steel Lateral

Material
WPHY 60 Carbon Steel

Connection
Welded

Shape
Lateral

Standard
ASTM A860

Surface Treatment
Black Painting or Anti-rust Oil

Outer Diameter
1/2 to 48

Section Shape
Round

Length
Custom as per requirement

Thickness
5mm - 50mm

Color
Black

Usage
Oil and Gas, Petrochemical, Power Plant

Rated Pressure
Schedule 10 to Schedule 160/XXS

Application
Pipeline System

Material Grade
WPHY 60

Packing Details
Wooden Cases, Pallets, or as per request

Shape Angle
45 and 60 degree lateral available

Corrosion Resistance
High due to coating options

Impact Testing
Performed as per ASTM requirements

Manufacturing Process
Seamless and Welded

Inspection
Third-party inspection available

End Type
Plain Ends / Bevelled Ends

Hardness
HRB 75-90

About WPHY 60 Carbon Steel Lateral

OUR EXPORT MARKET: Dubai, UAE, Malaysia, South Africa, Iran, Singapore, Canada, Colombia
TEST CERTIFICATE
Mill Test Certificate as per EN 10204 / 3.1B
Lateral tee pipe fitting manufacturers, reducing lateral tee dimensions
Grade Specification: Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A860 WPHY 42 Pipe Fittings Manufacturers, asme b16.9 lateral tee manufacturer, 45 degree lateral pipe fitting manufacturers

WPHY 60 equivalent
A860 WPHY 60	A860 Grade WPHY 60 Fittings
A694 WPHY 60	A694 Grade F60 Flanges
A234 WPHY 60	A234 Grade WPB Carbon Steel Fittings A234 AISI 4130 High Strength Low Alloyed Steel Fittings

Product Name	Pipe Fittings, Buttweld Fittings, Reducer, Elbow, tee
Material	A234 WPB A105 A283-D A135-A A53-A A106-A A179-C A214-C A192 A226 A315-B A53-B A106-B A106-C A178-C A210-A-1 A210-C
Size	Size 1/4 to 48 Outside Diameter 13.7 mm to 1219 mm
Standard	ASTM/ANSI.B16.9 ASTM/ANSI B16.28 ASTM /ANSI B16.11 ASTM/ANSI B16.25 BS1965 BS1640DIN 2605 DIN2615 DIN2616 DIN2617 GB 12459-90 GB/T13401-92 GB/T21635 GB/T21634 JIS B2311 JISB2312 JISB2313 JISB2316 ISO 3419-1981 ISO5251-1981
Certificates	API5L, ISO 9001:2008,SGS, BV,CCIC
Wall thickness	SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80, SCH100 SCH120, SCH160, XS, XXS
Surface Treatment	black paint, varnish, oil, galvanized, anti corrosion coatings
Marking	Wooden case & pallet
Pipe Ends	Under 2 inch plain end. 2 inch and above Beveled. Plastic caps (small OD) ,Iron protector (large OD)
Pipe Length	1. Single Random Length and double Random Length. 2. SRL:3M-5.8M DRL:10-11.8M or As clients requested length 3. fixed length(5.8m, 6m, 12m)
Packaging	Loose package; Packaged in bundles (2Ton Max); bundled pipes with two slings at the both end for easy loading and discharging; End with Plastic caps; wooden cases.
Test	Chemical Component Analysis, Mechanical Properties, Technical Properties, Exterior Size Inspection, hydraulic testing , X-ray Test.
Application	liquid delivery; Structure pipe; High and low pressure Boiler tube; Seamless steel tubes for petroleum cracking; oil pipe; gas pipe.
Why us?	1.Reasonable price with excellent quality 2.Abundant stock and prompt delivery 3.Rich supply and export experience, sincere service 4.Reliable forwarder, 2-hour away from port.

Standard	Description
ASTM A182/A182M	Forged or rolled alloy steel pipe flanges, forged fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASTM A403/A403M	Wrought austenitic stainless steel piping fittings.
ASTM A815/A815M	Wrought ferritic, ferritic/austenitic and martensitic stainless steel piping fittings.
AS 2129	Flanges for pipes, valves and fittings
ANSI/ASME B1.20.1	Pipe threads, general purpose (inch).
ANSI B16.5	Steel pipe flanges and flanged fittings.
ANSI B16.9	Factory-made wrought steel butt-welding fittings.
ANSI B16.11	Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings
ANSI B16.25	Butt-welding ends.
MSS SP43	Wrought stainless steel butt-welding fittings. Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
BS21	Threading.
ISO 4144	Stainless steel fittings threaded to ISO 7-1.
MSS SP-95	Swage(d) Nipples and Bull Plugs
BS3799	Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
ANSI B 16.9 ASTM A403 ASME SA403	Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
API 590-605 ASME B16.9	Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends
ASME B16.28	Wrought Steel Buttwelding Short Radius Elbows and Returns

Robust Manufacturing and Customization

Our WPHY 60 Carbon Steel Laterals are manufactured using both seamless and welded methods. Available with plain or bevelled ends, each fitting is produced to strict ASTM A860 standards. Customers can request lengths, diameters, and bend angles to suit their unique pipeline requirements, ensuring optimal fit and performance in any system.

Superior Durability and Corrosion Resistance

These laterals are treated with black painting, anti-rust oil, or advanced epoxy coatings, offering high corrosion resistance. Designed to operate in temperatures from -45C to 600C, they maintain strength and reliability even in harsh environments. Each fitting is inspected by third-party agencies and undergoes impact testing as per ASTM requirements, guaranteeing consistent quality.

Versatile Usage in Critical Applications

WPHY 60 Carbon Steel Laterals are ideal for applications in oil and gas, petrochemical, and power plant sectors. Featuring a rigid construction with metal-to-metal sealing and precise dimensions, these laterals withstand high pressures (Schedule 10 to 160/XXS) and are built for integration into complex pipeline systems-their versatility makes them suitable for new installations or retrofits alike.

FAQ's of WPHY 60 Carbon Steel Lateral:

Q: How are WPHY 60 Carbon Steel Laterals manufactured?

A: WPHY 60 Carbon Steel Laterals are manufactured using seamless or welded processes, complying with ASTM A860 standards. The choice of manufacturing process depends on the application requirements, ensuring strength and integrity in every fitting.

Q: What coating options are available to enhance corrosion resistance?

A: To improve corrosion resistance, these laterals can be supplied with black painting, anti-rust oil, or epoxy coatings. Customers can select the most suitable coating option based on their operation environment and system needs.

Q: When is impact testing performed on these fittings?

A: Impact testing is conducted as per ASTM requirements during the quality assurance process. This ensures that each lateral fitting meets strict standards for toughness, particularly when used in demanding temperature and pressure conditions.

Q: Where can these laterals be used?

A: WPHY 60 Carbon Steel Laterals are widely utilized in oil and gas pipelines, petrochemical networks, and power plants. Their high strength and corrosion resistance make them ideal for critical pipeline infrastructure, both in new projects and for system upgrades.

Q: What are the main benefits of using WPHY 60 Carbon Steel Laterals?

A: These laterals offer exceptional mechanical strength, high corrosion resistance, a wide temperature tolerance, and precise dimensional control (0.5mm). Their versatility and reliability reduce maintenance needs and enhance overall system durability.

Q: How does the inspection and packing process ensure product quality?

A: Each lateral undergoes thorough inspection, including optional third-party assessment and ASTM-standard impact testing. For secure transport and delivery, fittings are packed in wooden cases, on pallets, or as per specific customer requests.

Q: What connection types and end options are available for installation?

A: The laterals are designed with plain or bevelled ends for butt weld connections. This configuration allows for a secure, leak-free fit in a variety of welding and installation methods across multiple pipeline systems.
