WPHY 65 Carbon Steel Pipe Bend And Piggable Bend

Send Inquiry

Request To Call Back

WPHY 65 Carbon Steel Pipe Bend And Piggable Bend

Get a Price/Quote

WPHY 65 Carbon Steel Pipe Bend And Piggable Bend Specification

Coating Type
Customized/Black paint/Anti-corrosive

Diameter
Seamless up to 24 Inch, Welded up to 48 Inch

Connection Type
Butt Weld

Tolerance
1% on dimensions

Sealing Type
Welded Joint

Temperature Range
-46C to 600C

Flexibility
High (Suitable for pigging operations)

Tensile Strength
655 MPa

Thread Type
N/A (Beveled Ends Standard)

Bend Radius
R=1D to 10D (Customized)

Yield Strength
450 MPa min

Product Type
Pipe Bend, Piggable Bend

Material
WPHY 65 Carbon Steel

Connection
Welded / Beveled Ends

Shape
Bend

Standard
ASTM A860, MSS-SP-75, ASME B16.49

Surface Treatment
Black Painted / Anti-Rust Oil / Galvanized

Outer Diameter
1/2 Inch to 48 Inch (DN15 - DN1200)

Section Shape
Round

Length
as per requirement / Customized

Thickness
SCH10 to SCH160 (Customized)

Color
Black

Usage
Pipeline, Oil & Gas, Petrochemical, Power Industry

Rated Pressure
Class 150 to Class 2500

Material Grade
WPHY 65 (High Strength)

Application
Pipe Systems, Transmission Lines

Marking
Standard Marking as per Specification

Corrosion Resistance
High due to coating options

Inspection & Testing
100% Radiography, Ultrasonic, Hydrostatic Test

Packaging
Steel pallet/wooden cases with plastic caps

End Preparation
Beveled as per ASME B16.25

Availability
Ready Stock / Made to Order

Minimum Order Quantity
As per Requirement

Manufacturing Process
Hot Induction Bend / Cold Bend / Mandrel Bend

About WPHY 65 Carbon Steel Pipe Bend And Piggable Bend

RANGE : 2NB TO 18NB IN SCH: 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75

TYPE : SEAMLESS / WELDED/ FABRICATED

Form : Long radius Bend, Piggable Bend, Hot bend, With R=3D, 5D, 6D, 8D, 10D & Customized Bend

Offer : Minimum Wall Thinning rate & Ovality, No Wrinkles
Piggable Bend

Alloy Steel Piggable Bend
ASTM A 234 WP-P5, P9, P11, P12, P21, P22 & P91

Carbon Steel Piggable Bend
ASTM A 234 WPB,

Low Temperature Carbon Steel Piggable Bend
ASTM A 234 WPB

Grade Specification: Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A860 WPHY 42 Pipe Fittings Manufacturers

WPHY 65 equivalent
A860 WPHY 65	A860 Grade WPHY 65 Fittings
A694 WPHY 65	A694 Grade F65 Flanges
A234 WPHY 65	A234 Grade WPB Carbon Steel Fittings A234 AISI 4130 High Strength Low Alloyed Steel Fittings

Grade Specification	Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A420 WPL6
WPHY 65 Fittings Size	Seamless:from 1/2 to 24
WPHY 65 Fittings Size	Welded:from 24 to 96 (or as customer requirements)
WPHY 65 Fittings Degree	22.5 deg, 30deg,45 deg,90 deg,180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D,4D,5D,6D,7D-40D.
WPHY 65 Fittings Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH80., SCH100, SCH120, SCH140, SCH160, XXS
Standard	ASME B16.9, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO
Carbon Steel Material	Carbon steel (ASTM A234 WPB, A234WPC, A420 WPL6, etc)
	Stainless steel (ASTM A403 WP304, 304L, 316, 316L, 321,etc)
	Alloy steel (ASTM A234 WP12, WP11, WP22, WP5, WP9, WP91, etc)
WPHY 65 Fittings Type	Seamless / Welded / Fabricated
WPHY 65 Fittings Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
WPHY 65 Fittings Range	NB to 48 NB in Sch 10s, 40s, 80s, 160s, XXS. From 1/2 to 30 (Seamless Pipe Fittings), Form16 to 100 (Seam Pipe Fittings)
Dimensions	ANSI/ASME B16.9, B16.28, MSS-SP-43.
Applicable Standards	1-ASME B 16.9 for large Bore 2-ASME B 16.11 for small Bore (socket welded) 3-ASME B 16.25 for butt weld ends 4-ASME B 16.28 for small radius elbow
Seamless/ Welded 100% Radiography Tested

Standard	Description
ASTM A182/A182M	Forged or rolled alloy steel pipe flanges, forged fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASTM A403/A403M	Wrought austenitic stainless steel piping fittings.
ASTM A815/A815M	Wrought ferritic, ferritic/austenitic and martensitic stainless steel piping fittings.
AS 2129	Flanges for pipes, valves and fittings
ANSI/ASME B1.20.1	Pipe threads, general purpose (inch).
ANSI B16.5	Steel pipe flanges and flanged fittings.
ANSI B16.9	Factory-made wrought steel butt-welding fittings.
ANSI B16.11	Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings
ANSI B16.25	Butt-welding ends.
MSS SP43	Wrought stainless steel butt-welding fittings. Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
BS21	Threading.
ISO 4144	Stainless steel fittings threaded to ISO 7-1.
MSS SP-95	Swage(d) Nipples and Bull Plugs
BS3799	Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
ANSI B 16.9 ASTM A403 ASME SA403	Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
API 590-605 ASME B16.9	Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends
ASME B16.28	Wrought Steel Buttwelding Short Radius Elbows and Returns

Precision Manufacturing Meets Rigorous Standards

Every WPHY 65 Carbon Steel Pipe Bend is manufactured under strict quality control, utilizing hot induction, cold, or mandrel bend techniques to ensure optimal strength and dimensional accuracy. Beveled ends are prepared as per ASME B16.25 for seamless integration into pipeline systems. Each bend is meticulously inspected through 100% radiography, ultrasonic, and hydrostatic tests, guaranteeing compliance with ASTM, ASME, and MSS specifications.

Engineered for Durability and Corrosion Resistance

Our pipe bends are built to endure harsh environments with multiple coating options such as black paint, anti-corrosive oil, or galvanizing, significantly enhancing corrosion resistance. This adaptability enables use across oil & gas, petrochemical, and power industries, where performance and reliability are crucial.

Versatility in Application and Configuration

Available in seamless (up to 24 inch) and welded (up to 48 inch) types, these bends fit diverse requirements in pipeline transmission and distribution. Their high flexibility accommodates pigging operations, while customizable bend radii (R=1D to 10D) and wall thicknesses (SCH10 to SCH160) allow tailored solutions for a wide range of pipeline layouts and flow requirements.

FAQ's of WPHY 65 Carbon Steel Pipe Bend And Piggable Bend:

Q: How are WPHY 65 Carbon Steel Pipe Bends manufactured?

A: WPHY 65 Carbon Steel Pipe Bends are produced through hot induction, cold bending, or mandrel bending processes, offering precise shapes and strength. Each piece is bevel-ended as per ASME B16.25 to ensure proper alignment and welding.

Q: What inspection and testing methods are used to ensure quality?

A: Every product undergoes 100% radiographic, ultrasonic, and hydrostatic testing. These rigorous inspections guarantee structural integrity, dimensional accuracy (with 1% tolerance), and conformance to relevant ASTM, ASME, and MSS standards.

Q: When should piggable bends be used in pipeline systems?

A: Piggable bends are recommended when pipeline maintenance involves pigging-using devices to clean or inspect pipe interiors. Their high flexibility and precise dimensions support smooth pig operations, reducing flow restrictions and maintenance costs.

Q: Where are these carbon steel bends commonly applied?

A: These bends are extensively applied in oil & gas pipelines, petrochemical distribution, power generation facilities, and transmission lines-especially where high pressure, temperature, and durability are essential requirements.

Q: What surface treatments are available for corrosion resistance?

A: Depending on project needs, options include black painted, anti-rust oil coated, and galvanized finishes. These surface treatments enhance longevity, making the bends suitable for challenging chemical and environmental exposures.

Q: How do customers benefit from your supply flexibility and quality assurance?

A: Clients enjoy ready stock availability or customized production, minimum order quantities tailored as needed, and secure packaging in steel pallets or wooden cases. Comprehensive marking and documentation support traceability and ease of installation.
