WPHY 65 Carbon Steel Pipe Nipples

Get a Price/Quote

WPHY 65 Carbon Steel Pipe Nipples Specification

Connection Type
Male Threaded / Welded

Sealing Type
Threaded Joint / Welded Joint

Tensile Strength
485 MPa (min)

Yield Strength
415 MPa (min)

Coating Type
Anti-corrosive Coating

Temperature Range
-29C to +90C

Tolerance
0.5 mm

Flexibility
Rigid

Thread Type
NPT / BSP

Diameter
12 mm to 150 mm

Product Type
Pipe Nipple

Material
WPHY 65 Carbon Steel

Connection
Threaded / Beveled Ends

Shape
Cylindrical

Standard
ASTM A860

Surface Treatment
Black Painted / Anti-Rust Coated

Outer Diameter
1/2 inch to 6 inch (custom sizes available)

Section Shape
Round

Length
2 inches to 24 inches (custom lengths available)

Thickness
Sch 40 / Sch 80 / Custom

Color
Black

Usage
Oil & Gas, Petrochemical, Water Supply

Rated Pressure
up to 6000 PSI

Material Grade
WPHY 65

Application
High Pressure Pipe Fittings

Packing
Plastic Cap & Protective Sleeve

Resistant To
Corrosion, Shock, Abrasion

Hardness
90 HRB (max)

Service Life
Long-lasting under severe conditions

Manufacturing Process
Hot Finished / Cold Drawn

End Finish
Plain, Beveled, or Threaded

Marking
Size, Grade & Heat No. Stamped

Weight
As per size & schedule

Pipe Type
Buttweld / Socket Weld / Screwed

Inspection
100% Dimensional & Visual Checked

Impact Value
27J at -20C

About WPHY 65 Carbon Steel Pipe Nipples

OUR EXPORT MARKET: Dubai, UAE, Malaysia, South Africa, Iran, Singapore, Canada, Colombia

TEST CERTIFICATE

Mill Test Certificate as per EN 10204 / 3.1B

Grade Specification: Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A860 WPHY 42 Pipe Fittings Manufacturers

WPHY 65 equivalent
A860 WPHY 65	A860 Grade WPHY 65 Fittings
A694 WPHY 65	A694 Grade F65 Flanges
A234 WPHY 65	A234 Grade WPB Carbon Steel Fittings A234 AISI 4130 High Strength Low Alloyed Steel Fittings

Grade Specification	Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A420 WPL6
WPHY 65 Fittings Size	Seamless:from 1/2 to 24
WPHY 65 Fittings Size	Welded:from 24 to 96 (or as customer requirements)
WPHY 65 Fittings Degree	22.5 deg, 30deg,45 deg,90 deg,180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D,4D,5D,6D,7D-40D.
WPHY 65 Fittings Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH80., SCH100, SCH120, SCH140, SCH160, XXS
Standard	ASME B16.9, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO
Carbon Steel Material	Carbon steel (ASTM A234 WPB, A234WPC, A420 WPL6, etc)
	Stainless steel (ASTM A403 WP304, 304L, 316, 316L, 321,etc)
	Alloy steel (ASTM A234 WP12, WP11, WP22, WP5, WP9, WP91, etc)
WPHY 65 Fittings Type	Seamless / Welded / Fabricated
WPHY 65 Fittings Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
WPHY 65 Fittings Range	NB to 48 NB in Sch 10s, 40s, 80s, 160s, XXS. From 1/2 to 30 (Seamless Pipe Fittings), Form16 to 100 (Seam Pipe Fittings)
Dimensions	ANSI/ASME B16.9, B16.28, MSS-SP-43.
Applicable Standards	1-ASME B 16.9 for large Bore 2-ASME B 16.11 for small Bore (socket welded) 3-ASME B 16.25 for butt weld ends 4-ASME B 16.28 for small radius elbow
Seamless/ Welded 100% Radiography Tested

Standard	Description
ASTM A182/A182M	Forged or rolled alloy steel pipe flanges, forged fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASTM A403/A403M	Wrought austenitic stainless steel piping fittings.
ASTM A815/A815M	Wrought ferritic, ferritic/austenitic and martensitic stainless steel piping fittings.
AS 2129	Flanges for pipes, valves and fittings
ANSI/ASME B1.20.1	Pipe threads, general purpose (inch).
ANSI B16.5	Steel pipe flanges and flanged fittings.
ANSI B16.9	Factory-made wrought steel butt-welding fittings.
ANSI B16.11	Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings
ANSI B16.25	Butt-welding ends.
MSS SP43	Wrought stainless steel butt-welding fittings. Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
BS21	Threading.
ISO 4144	Stainless steel fittings threaded to ISO 7-1.
MSS SP-95	Swage(d) Nipples and Bull Plugs
BS3799	Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
ANSI B 16.9 ASTM A403 ASME SA403	Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
API 590-605 ASME B16.9	Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends
ASME B16.28	Wrought Steel Buttwelding Short Radius Elbows and Returns

Superior Material Strength and Durability

WPHY 65 pipe nipples deliver high mechanical strength with a minimum tensile strength of 485 MPa and a yield strength of at least 415 MPa. These properties make them perfect for high-pressure applications, offering a service life that endures even severe industrial conditions.

Versatile End Finishes and Custom Dimensions

Choose from plain, beveled, or threaded end finishes to suit your installation requirements. Available in custom lengths and diameters ranging from 12 mm to 150 mm, these nipples cater to a wide range of project specifications, ensuring an exact fit.

Comprehensive Protection and Compliance

Every nipple is surface treated with either black paint or an anti-corrosive coating for outstanding protection. Each item is 100% dimensionally and visually inspected and clearly marked for traceability, complying with the stringent ASTM A860 standard.

FAQ's of WPHY 65 Carbon Steel Pipe Nipples:

Q: How are WPHY 65 Carbon Steel Pipe Nipples manufactured?

A: These nipples are produced by hot-finished or cold-drawn methods, ensuring precise dimensions and superior strength. Each product undergoes 100% dimensional and visual inspection to meet strict quality standards.

Q: What end finishes and connection types are available for these pipe nipples?

A: WPHY 65 Carbon Steel Pipe Nipples come with plain, beveled, or threaded ends. Connection options include male threaded joints, welded joints, and they can be tailored for buttweld, socket weld, or screwed applications.

Q: When should I use WPHY 65 pipe nipples in my project?

A: These pipe nipples are ideal for high-pressure environments, such as oil & gas, petrochemical, and water supply lines, especially where resistance to corrosion, shock, and abrasion is essential.

Q: Where are these pipe nipples commonly installed?

A: WPHY 65 Carbon Steel Pipe Nipples are widely used in high-pressure pipelines and fittings in industries like oil & gas, petrochemical, and water utilities.

Q: What benefits do black paint or anti-rust coated finishes provide?

A: Both surface treatments enhance resistance to corrosion and wear, ensuring a longer service life and maintaining performance in harsh or corrosive environments.

Q: How is product traceability ensured for each nipple?

A: Each pipe nipple is stamped with its size, grade, and heat number. This marking provides complete traceability back to the manufacturing batch, guaranteeing quality and compliance.

Q: What are the customization options for dimensions and schedules?

A: Pipe nipples can be ordered in outer diameters from 1/2 inch to 6 inch (12 mm to 150 mm) and in lengths from 2 inches up to 24 inches. Custom schedules and thicknesses are also available upon request.
