WPHY 56 Carbon Steel Cross Fitting

Get a Price/Quote

WPHY 56 Carbon Steel Cross Fitting Specification

Coating Type
Black Paint/Anti-Corrosion

Tensile Strength
485 MPa

Thread Type
Not Threaded

Connection Type
Welded

Yield Strength
390 MPa

Bend Radius
Standard as per ASME

Diameter
As per Specification

Temperature Range
-46C to +600C

Tolerance
0.5 mm

Flexibility
Rigid

Sealing Type
Butt Welded Joint

Product Type
Cross Fitting

Material
WPHY 56 Carbon Steel

Connection
Butt Weld

Shape
Cross

Standard
ASME B16.9 / MSS-SP 75

Surface Treatment
Black Painted, Anti-Rust Oil

Outer Diameter
1/2 to 48 (DN15 to DN1200)

Section Shape
Round

Length
Customizable

Thickness
Sch 10 to Sch XXS

Color
Black

Usage
Pipeline, Oil & Gas, Petrochemical

Rated Pressure
Up to 6000 PSI

Application
High Pressure Fluid Handling

Material Grade
ASTM A860 WPHY 56

End Connection
Beveled Ends

Marking
Size, Grade, Heat No., Manufacturers Logo

Corrosion Resistance
Excellent with proper coating

Weight
Depends on Dimension & Thickness

Hardness
Approximates to 163 HB

Packaging
Wooden Cases / Pallets

Manufacturing Process
Seamless/ Welded

Wall Thickness
ANSI B36.10/ B36.19

Testing
Ultrasonic, Hydro-static, PMI, Visual and Dimension

About WPHY 56 Carbon Steel Cross Fitting

Pipe cross manufacturers in India

Standard: ANSI B16.9 / 16.28, ASTM A53/A106, API 5L, ASME B36.10M1996, DIN2605 / 2615 / 2616, JIS P2311/2312
Thickness: SGP, STD, SCH40, SCH80, SCH160. XS, XXS and so on.
Size: 1/260
Material: Carbon steel , alloy steel, stainless steel
Surface treatment: Transparent oil, rust-proof black oil or hot galvanized.

Seamless cross
Erw cross
pipe cross
carbon steel cross

Grade Specification: Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A860 WPHY 42 Pipe Fittings Manufacturers

WPHY 56 equivalent
A860 WPHY 56	A860 Grade WPHY 56 Fittings
A694 WPHY 56	A694 Grade F56 Flanges
A234 WPHY 56	A234 Grade WPB Carbon Steel Fittings A234 AISI 4130 High Strength Low Alloyed Steel Fittings

Size	Seamless: from 1/2 to 24
Size	Welded: from 24 to 96( or as customer requirements)
Type	Equal tee, Reduced Tee, Lateral Tee,
Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH80, SCH100, SCH120, SCH140, SCH160, XXS
standard	ASME B16.9, ASME B16.25, MSS SP-75 DIN2615 JISB2311 JISB2312 JISB2313
material	Carbon steel (ASTM A234WPB, A234WPC, A420WPL6, etc
	Stainless steel (ASTM A403 WP304, 304L, 316, 316L, 321, etc
	Alloy steel (ASTM A234 WP12, WP11, WP22, WP5, WP9, WP91, etc
qualification	ISO9001:2008 , ISO 14001 OHSAS18001 , API , etc
packing	in wooded cases or pallets, or as for clientsrequirements
application	Petroleum, chemical, machinery, electric power, shipbuilding, papermaking, construction, etc
equipment	Huge Heat treatment furnace, RW-1500 lenge size radius induction pusher, CG1600T-DB1200 induction pusher, A grooving machine, Tube spraying grit treatment, etc
testing	Dircet reading spectrometer, Mechanical testing, Super living inspection, Magentic particle inspection, etc

Standard	Description
ASTM A182/A182M	Forged or rolled alloy steel pipe flanges, forged fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASTM A403/A403M	Wrought austenitic stainless steel piping fittings.
ASTM A815/A815M	Wrought ferritic, ferritic/austenitic and martensitic stainless steel piping fittings.
AS 2129	Flanges for pipes, valves and fittings
ANSI/ASME B1.20.1	Pipe threads, general purpose (inch).
ANSI B16.5	Steel pipe flanges and flanged fittings.
ANSI B16.9	Factory-made wrought steel butt-welding fittings.
ANSI B16.11	Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings
ANSI B16.25	Butt-welding ends.
MSS SP43	Wrought stainless steel butt-welding fittings. Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
BS21	Threading.
ISO 4144	Stainless steel fittings threaded to ISO 7-1.
MSS SP-95	Swage(d) Nipples and Bull Plugs
BS3799	Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
ANSI B 16.9 ASTM A403 ASME SA403	Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
API 590-605 ASME B16.9	Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends
ASME B16.28	Wrought Steel Buttwelding Short Radius Elbows and Returns

High-Performance Cross Fitting for Demanding Pipelines

Designed for critical environments, the WPHY 56 Carbon Steel Cross Fitting delivers exceptional strength and resistance. Its customizable features comply with global standards, offering versatility for new installations and retrofits in oil & gas and petrochemical industries. Supported by stringent quality testing, these fittings guarantee secure connections and lasting durability, even in harsh operating conditions.

Precision Engineering and Tested Reliability

Manufactured with attention to material composition and wall thickness as per ANSI B36.10/19, this cross fitting undergoes comprehensive non-destructive testing. The markings provide complete traceability, including size, grade, manufacturer's logo, and heat number. This systematic approach ensures that each fitting meets rigorous performance and safety criteria, facilitating worry-free operations.

FAQ's of WPHY 56 Carbon Steel Cross Fitting:

Q: How is the WPHY 56 Carbon Steel Cross Fitting suited for high-pressure fluid handling?

A: The WPHY 56 Cross Fitting is built with a high tensile strength (485 MPa) and yield strength (390 MPa), making it ideal for applications up to 6000 PSI. Its seamless or welded construction, combined with strict testing protocols, enables it to withstand demanding, high-pressure environments in pipelines, oil & gas, and petrochemical sectors.

Q: What standards and specifications does this fitting conform to?

A: It strictly follows ASME B16.9 and MSS-SP 75 standards, with wall thicknesses as per ANSI B36.10/B36.19. The material grade is ASTM A860 WPHY 56, ensuring compatibility and safety for global pipeline projects.

Q: When should I choose a cross fitting with beveled ends and butt weld connection?

A: Beveled ends and butt weld connections are recommended for permanent, leak-resistant joints that can handle high pressures and temperatures. This makes the fitting perfect for critical industrial pipelines where reliability is paramount.

Q: Where can the WPHY 56 Cross Fitting be used?

A: It is suitable for installation in pipeline systems across oil & gas, petrochemical plants, and any industrial setting that requires safe transfer of high-pressure fluids and gases.

Q: What is the manufacturing and testing process for this fitting?

A: Each fitting is manufactured from WPHY 56 Carbon Steel, either seamlessly or by welding. It undergoes ultrasonic, hydro-static, PMI, visual, and dimensional inspections to ensure structural integrity and compliance with industry standards.

Q: How does the product ensure corrosion resistance and durability?

A: The cross fitting receives a coating of black paint or anti-corrosion oil, offering excellent resistance to corrosion when properly maintained. This protective treatment prolongs the fitting's lifespan in aggressive environments.

Q: What are the packaging and marking details provided?

A: Fittings are packed in sturdy wooden cases or pallets to avoid damage during transit. Each item is clearly marked with its size, grade, heat number, and manufacturer's logo to ensure full product traceability and compliance.
