WPHY 56 Carbon Steel Reducers

Get a Price/Quote

WPHY 56 Carbon Steel Reducers Specification

Flexibility
Rigid

Tensile Strength
570 MPa (min)

Tolerance
0.5 mm

Connection Type
Butt Welded

Sealing Type
Butt Welded, Leak Proof

Coating Type
Black Paint / Epoxy Coated (Optional)

Temperature Range
-46C to 593C

Yield Strength
390 MPa (min)

Bend Radius
As per Design / Standard

Diameter
Customized per Requirement

Product Type
Reducer

Material
Carbon Steel

Connection
Welded

Shape
Concentric / Eccentric

Standard
ASTM A860 / MSS SP 75

Surface Treatment
Black Painted / Anti-Rust Oil

Outer Diameter
1/2 to 48 (DN15 to DN1200)

Section Shape
Round

Length
As per Standard or Custom

Thickness
SCH 20 to SCH XXS, Custom As Required

Color
Black

Usage
Pipeline Connection, Flow Reduction

Rated Pressure
Class 300 to Class 2500

Material Grade
WPHY 56

Application
Oil & Gas, Petrochemical, Power Plant, Water Supply, etc.

Minimum Order Quantity
1 Piece

Weight
As per Size & Thickness

Compliance
NACE MR0175 / ISO 15156 (Optional)

Inspection
100% Radiography, Ultrasonic Testing (UT), MPI

End Type
Plain / Beveled

Packing
Wooden Boxes / Pallets / As per Requirement

Manufacturing Process
Seamless / Welded / Forged

Impact Test
Available as per Requirement

Corrosion Resistance
High, with Surface Coating

Design
Standard Conforms to ASME B16.9 / B16.28

Hardness
BHN 179 217

About WPHY 56 Carbon Steel Reducers

WPHY 42 Reducers Concentric & Eccentric Reducers
Looking for WPHY 42 Reducers in specific standards & size at Factory Rate?
We are manufacturers of WPHY 42 Reducers and supply high quality WPHY 42 Reducers in both large and small quantities worldwide & offer you the best prices in the market.
We can also offer customized packaging for WPHY 42 Reducers as per customers requirement.
Grade Specification: Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A860 WPHY 42 Pipe Fittings Manufacturers

WPHY 56 equivalent
A860 WPHY 56	A860 Grade WPHY 56 Fittings
A694 WPHY 56	A694 Grade F56 Flanges
A234 WPHY 56	A234 Grade WPB Carbon Steel Fittings A234 AISI 4130 High Strength Low Alloyed Steel Fittings

Size	Seamless: from 1/2 to 24
Size	Welded: from 24 to 96( or as customer requirements)
Type	Equal tee, Reduced Tee, Lateral Tee,
Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH80, SCH100, SCH120, SCH140, SCH160, XXS
standard	ASME B16.9, ASME B16.25, MSS SP-75 DIN2615 JISB2311 JISB2312 JISB2313
material	Carbon steel (ASTM A234WPB, A234WPC, A420WPL6, etc
	Stainless steel (ASTM A403 WP304, 304L, 316, 316L, 321, etc
	Alloy steel (ASTM A234 WP12, WP11, WP22, WP5, WP9, WP91, etc
qualification	ISO9001:2008 , ISO 14001 OHSAS18001 , API , etc
packing	in wooded cases or pallets, or as for clientsrequirements
application	Petroleum, chemical, machinery, electric power, shipbuilding, papermaking, construction, etc
equipment	Huge Heat treatment furnace, RW-1500 lenge size radius induction pusher, CG1600T-DB1200 induction pusher, A grooving machine, Tube spraying grit treatment, etc
testing	Dircet reading spectrometer, Mechanical testing, Super living inspection, Magentic particle inspection, etc

Standard	Description
ASTM A182/A182M	Forged or rolled alloy steel pipe flanges, forged fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASTM A403/A403M	Wrought austenitic stainless steel piping fittings.
ASTM A815/A815M	Wrought ferritic, ferritic/austenitic and martensitic stainless steel piping fittings.
AS 2129	Flanges for pipes, valves and fittings
ANSI/ASME B1.20.1	Pipe threads, general purpose (inch).
ANSI B16.5	Steel pipe flanges and flanged fittings.
ANSI B16.9	Factory-made wrought steel butt-welding fittings.
ANSI B16.11	Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings
ANSI B16.25	Butt-welding ends.
MSS SP43	Wrought stainless steel butt-welding fittings. Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
BS21	Threading.
ISO 4144	Stainless steel fittings threaded to ISO 7-1.
MSS SP-95	Swage(d) Nipples and Bull Plugs
BS3799	Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
ANSI B 16.9 ASTM A403 ASME SA403	Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
API 590-605 ASME B16.9	Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends
ASME B16.28	Wrought Steel Buttwelding Short Radius Elbows and Returns

Superior Performance & Corrosion Resistance

Each WPHY 56 Carbon Steel Reducer is designed for demanding conditions, providing high resistance to corrosion with surface treatments like black paint or anti-rust oil. This ensures reliability in harsh environments such as oil & gas fields, petrochemical plants, and power stations. The reducers meet strict industry standards, delivering consistent performance and reducing the risk of leaks or failures.

Tailored Manufacturing & Quality Assurance

Manufactured through seamless, welded, or forged processes, every reducer undergoes 100% radiography, ultrasonic testing, and MPI inspections. This meticulous quality control guarantees integrity and compliance with ASME, ASTM, NACE, and ISO standards. Custom dimensions, thicknesses, and coating options are available, enabling perfect integration with diverse pipeline systems.

Versatility & Broad Applications

These reducers suit a wide range of uses-from flow reduction in pipelines to adapting diameters in water supply systems. Compliant with multiple pressure classes (Class 300 to 2500) and a wide temperature range (-46C to 593C), they offer flexibility and compatibility for various industrial sectors.

FAQ's of WPHY 56 Carbon Steel Reducers:

Q: How are WPHY 56 Carbon Steel Reducers manufactured to ensure durability?

A: These reducers are produced using seamless, welded, or forged processes, followed by rigorous testing such as 100% radiography, ultrasonic testing, and magnetic particle inspection (MPI). This ensures each piece meets strict strength and integrity requirements for demanding environments.

Q: What benefits do high corrosion resistance and surface coatings provide?

A: The high corrosion resistance, enhanced by black paint or anti-rust oil coatings, significantly extends service life, reduces maintenance needs, and ensures performance stability in aggressive chemical and weather conditions.

Q: When should I opt for concentric versus eccentric reducer shapes?

A: Select concentric reducers to maintain a centerline for vertical flows, while eccentric reducers are ideal for horizontal flows to prevent air pockets and ensure efficient drainage in pipeline systems.

Q: Where are WPHY 56 Carbon Steel Reducers commonly used?

A: These reducers are widely applied in oil & gas pipelines, petrochemical installations, power plants, and water supply systems, where robust and leak-proof performance under pressure and temperature variations is essential.

Q: What is the process for ordering customized reducers, and what is the minimum order quantity?

A: Customized reducers can be ordered to match specific diameters, thicknesses, and coatings. The minimum order quantity is just one piece, and products can be packed in wooden boxes, pallets, or as required for secure transportation.

Q: How does compliance with standards like ASME B16.9 and NACE MR0175 benefit the user?

A: Compliance ensures compatibility with existing systems, international safety, and quality standards. This facilitates easier integration, reliable performance, and adherence to industry regulations for critical processes.

Q: What impact and pressure ratings do these reducers offer?

A: Impact testing is available as needed, and the reducers are rated for pressures from Class 300 to Class 2500, accommodating rigorous operation in high-stress and high-temperature pipeline environments.
