WPHY 60 Carbon Steel 180 Degree SR Return Bend

Get a Price/Quote

WPHY 60 Carbon Steel 180 Degree SR Return Bend Specification

Tensile Strength
415-690 MPa

Thread Type
N/A (Butt Welded Connection)

Tolerance
0.75 mm (as per standard)

Diameter
15 mm to 1200 mm

Sealing Type
Welded Joint metal to metal

Bend Radius
Short Radius (SR), 1D radius

Coating Type
Black Painting / Varnish

Flexibility
Rigid

Connection Type
Butt Welded

Temperature Range
-29C to +593C

Yield Strength
415 MPa min

Product Type
180 Degree SR Return Bend

Material
Carbon Steel

Connection
Butt Weld

Shape
Return Bend (180 Elbow)

Standard
ANSI/ASME B16.9, MSS SP-75

Surface Treatment
Black Painted / Anti-rust Oil Coated

Outer Diameter
1/2 inch to 48 inch (DN15 DN1200)

Section Shape
Round

Length
As per standard or customer requirement

Thickness
Sch 10 to Sch 160 & XXS

Color
Black

Usage
Pipeline, Oil & Gas, Petrochemical, Power Plant

Rated Pressure
Class 150-2500

Application
Fluid transportation, pipeline bending, high-pressure systems

Material Grade
WPHY 60

Ends
Bevelled

HS Code
73079300

Marking
Size, grade, standard, heat no.

Density
7.85 g/cm

Inspection
100% Radiography, Ultrasonic, Hydrostatic Testing

Packing
Wooden cases, pallets, as required

Corrosion Resistance
Moderate

Manufacturing Process
Hot forming, induction bending

OEM Availability
Yes

Hardness
217 HB max

About WPHY 60 Carbon Steel 180 Degree SR Return Bend

Product: Buttweld 180 Short Radius Elbow

Sizes: 1/2 TO 36 (SEAMLESS UPTO 24) (WELDED 8 TO 36 )

Standards: ANSI B 16.9
ASTM A403 ASME SA403 Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
API 590-605
ASME B16.9 Factory-Made Wrought Buttwelding Fittings
ASME B16.25 Buttwelding Ends
ASME B16.28 Wrought Steel Buttwelding Short Radius Elbows and Returns
MSS SP-43 Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications

Schedule: Sch 5 TO Sch XXS.

Thickness: Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.

Type: Buttweld (BW)

Grade Specification: Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A860 WPHY 42 Pipe Fittings Manufacturers

WPHY 60 equivalent
A860 WPHY 60	A860 Grade WPHY 60 Fittings
A694 WPHY 60	A694 Grade F60 Flanges
A234 WPHY 60	A234 Grade WPB Carbon Steel Fittings A234 AISI 4130 High Strength Low Alloyed Steel Fittings

Product Name	Pipe Fittings, Buttweld Fittings, Reducer, Elbow, tee
Material	A234 WPB A105 A283-D A135-A A53-A A106-A A179-C A214-C A192 A226 A315-B A53-B A106-B A106-C A178-C A210-A-1 A210-C
Size	Size 1/4 to 48 Outside Diameter 13.7 mm to 1219 mm
Standard	ASTM/ANSI.B16.9 ASTM/ANSI B16.28 ASTM /ANSI B16.11 ASTM/ANSI B16.25 BS1965 BS1640DIN 2605 DIN2615 DIN2616 DIN2617 GB 12459-90 GB/T13401-92 GB/T21635 GB/T21634 JIS B2311 JISB2312 JISB2313 JISB2316 ISO 3419-1981 ISO5251-1981
Certificates	API5L, ISO 9001:2008,SGS, BV,CCIC
Wall thickness	SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80, SCH100 SCH120, SCH160, XS, XXS
Surface Treatment	black paint, varnish, oil, galvanized, anti corrosion coatings
Marking	Wooden case & pallet
Pipe Ends	Under 2 inch plain end. 2 inch and above Beveled. Plastic caps (small OD) ,Iron protector (large OD)
Pipe Length	1. Single Random Length and double Random Length. 2. SRL:3M-5.8M DRL:10-11.8M or As clients requested length 3. fixed length(5.8m, 6m, 12m)
Packaging	Loose package; Packaged in bundles (2Ton Max); bundled pipes with two slings at the both end for easy loading and discharging; End with Plastic caps; wooden cases.
Test	Chemical Component Analysis, Mechanical Properties, Technical Properties, Exterior Size Inspection, hydraulic testing , X-ray Test.
Application	liquid delivery; Structure pipe; High and low pressure Boiler tube; Seamless steel tubes for petroleum cracking; oil pipe; gas pipe.
Why us?	1.Reasonable price with excellent quality 2.Abundant stock and prompt delivery 3.Rich supply and export experience, sincere service 4.Reliable forwarder, 2-hour away from port.

Standard	Description
ASTM A182/A182M	Forged or rolled alloy steel pipe flanges, forged fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASTM A403/A403M	Wrought austenitic stainless steel piping fittings.
ASTM A815/A815M	Wrought ferritic, ferritic/austenitic and martensitic stainless steel piping fittings.
AS 2129	Flanges for pipes, valves and fittings
ANSI/ASME B1.20.1	Pipe threads, general purpose (inch).
ANSI B16.5	Steel pipe flanges and flanged fittings.
ANSI B16.9	Factory-made wrought steel butt-welding fittings.
ANSI B16.11	Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings
ANSI B16.25	Butt-welding ends.
MSS SP43	Wrought stainless steel butt-welding fittings. Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
BS21	Threading.
ISO 4144	Stainless steel fittings threaded to ISO 7-1.
MSS SP-95	Swage(d) Nipples and Bull Plugs
BS3799	Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
ANSI B 16.9 ASTM A403 ASME SA403	Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
API 590-605 ASME B16.9	Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends
ASME B16.28	Wrought Steel Buttwelding Short Radius Elbows and Returns

Engineered for Durability and Performance

WPHY 60 Carbon Steel 180 Degree SR Return Bends are designed to withstand high-pressure, high-temperature fluid transport in critical pipeline systems. Their short radius curve ensures compact installation while maintaining optimal flow dynamics, making them an ideal choice for space-constrained industrial layouts.

Comprehensive Quality Control

Each return bend undergoes extensive testing processes-including 100% radiographic, ultrasonic, and hydrostatic inspections-to guarantee quality and safety. Markings for size, grade, standard, and heat number provide complete traceability, while specialized surface treatments enhance moderate corrosion resistance for long service life.

Versatility in Application and Supply

Suitable for integration in pipelines, petrochemical plants, and power generation facilities, these bends cater to varied thicknesses (Sch 10 to XXS), with customized options for length and packaging. Available through distributors, exporters, manufacturers, and suppliers, WPHY 60 bends are tailored to meet diverse project specifications worldwide.

FAQ's of WPHY 60 Carbon Steel 180 Degree SR Return Bend:

Q: How are WPHY 60 Carbon Steel 180 Degree SR Return Bends manufactured?

A: These bends are produced using hot forming or induction bending processes, which shape the carbon steel material while maintaining its mechanical properties. After forming, the ends are bevelled to facilitate secure butt-welded connections.

Q: What inspection methods are used to ensure quality for these return bends?

A: The bends undergo 100% radiographic, ultrasonic, and hydrostatic testing to confirm the absence of defects and guarantee structural integrity, complying with industry standards such as ANSI/ASME B16.9 and MSS SP-75.

Q: When should I use a 180 Degree Short Radius Return Bend in my piping system?

A: These return bends are used when a complete reversal of flow direction is needed over a short distance, particularly in compact pipelines or high-pressure/high-temperature environments like oil, gas, or chemical plants.

Q: Where can these WPHY 60 Return Bends be installed?

A: They are suitable for installations in oil and gas pipelines, petrochemical industries, water treatment facilities, and power plants-anywhere robust fluid transport and directional changes are required.

Q: What are the benefits of choosing WPHY 60 material for return bends?

A: WPHY 60 offers a combination of moderate corrosion resistance, high tensile (415-690 MPa), and yield strength (minimum 415 MPa), making it suitable for high-pressure applications while maintaining durability and performance.

Q: How do I determine the correct size and thickness for my application?

A: Sizes range from 1/2 inch to 48 inches, with available thickness from Sch 10 to XXS. Selection depends on the pipeline diameter, operating pressure, and specific application requirements. Consult with your supplier or refer to project specifications for guidance.
