WPHY 60 Carbon Steel Pipe Nipples

Get a Price/Quote

WPHY 60 Carbon Steel Pipe Nipples Specification

Diameter
As per Specification / Custom

Temperature Range
-20C to 593C

Sealing Type
Threaded Seal

Thread Type
NPT / BSPT

Connection Type
Threaded

Tolerance
0.5 mm

Flexibility
Rigid

Tensile Strength
414 MPa (Min)

Yield Strength
415 MPa (Min)

Coating Type
Black Coated / Custom

Product Type
Pipe Nipples

Material
Carbon Steel

Connection
Male Threaded

Shape
Round

Standard
ASTM A860 MSS SP-75

Surface Treatment
Black Painted / Anti-rust Coated

Outer Diameter
1/2 to 48 (DN15 - DN1200)

Section Shape
Cylindrical

Length
2 to 12 (Custom Lengths Available)

Thickness
Schedule 40 / 80 / Custom

Color
Black

Usage
Oil, Gas, Petrochemical, and Industrial Piping

Rated Pressure
Up to 6000 PSI

Material Grade
WPHY 60

Application
Piping Connection, Flow Control, Pressure Applications

Compatibility
Suitable for ANSI, DIN, JIS Flanges

Packaging
Plastic Caps on Ends, Bundled or as Required

Corrosion Resistance
Good (with Coating)

End Connection
Plain/Beveled/Threaded as per Requirement

Inspection
100% Hydrostatic and Visual Inspection

Manufacturing Process
Hot Finished / Seamless / Welded

Heat Treatment
Normalized / Quenched and Tempered

Marking
Size, Grade & Manufacturer Marked

About WPHY 60 Carbon Steel Pipe Nipples

OUR EXPORT MARKET: Dubai, UAE, Malaysia, South Africa, Iran, Singapore, Canada, Colombia

TEST CERTIFICATE

Mill Test Certificate as per EN 10204 / 3.1B

Grade Specification: Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A860 WPHY 42 Pipe Fittings Manufacturers

WPHY 60 equivalent
A860 WPHY 60	A860 Grade WPHY 60 Fittings
A694 WPHY 60	A694 Grade F60 Flanges
A234 WPHY 60	A234 Grade WPB Carbon Steel Fittings A234 AISI 4130 High Strength Low Alloyed Steel Fittings

Product Name	Pipe Fittings, Buttweld Fittings, Reducer, Elbow, tee
Material	A234 WPB A105 A283-D A135-A A53-A A106-A A179-C A214-C A192 A226 A315-B A53-B A106-B A106-C A178-C A210-A-1 A210-C
Size	Size 1/4 to 48 Outside Diameter 13.7 mm to 1219 mm
Standard	ASTM/ANSI.B16.9 ASTM/ANSI B16.28 ASTM /ANSI B16.11 ASTM/ANSI B16.25 BS1965 BS1640DIN 2605 DIN2615 DIN2616 DIN2617 GB 12459-90 GB/T13401-92 GB/T21635 GB/T21634 JIS B2311 JISB2312 JISB2313 JISB2316 ISO 3419-1981 ISO5251-1981
Certificates	API5L, ISO 9001:2008,SGS, BV,CCIC
Wall thickness	SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80, SCH100 SCH120, SCH160, XS, XXS
Surface Treatment	black paint, varnish, oil, galvanized, anti corrosion coatings
Marking	Wooden case & pallet
Pipe Ends	Under 2 inch plain end. 2 inch and above Beveled. Plastic caps (small OD) ,Iron protector (large OD)
Pipe Length	1. Single Random Length and double Random Length. 2. SRL:3M-5.8M DRL:10-11.8M or As clients requested length 3. fixed length(5.8m, 6m, 12m)
Packaging	Loose package; Packaged in bundles (2Ton Max); bundled pipes with two slings at the both end for easy loading and discharging; End with Plastic caps; wooden cases.
Test	Chemical Component Analysis, Mechanical Properties, Technical Properties, Exterior Size Inspection, hydraulic testing , X-ray Test.
Application	liquid delivery; Structure pipe; High and low pressure Boiler tube; Seamless steel tubes for petroleum cracking; oil pipe; gas pipe.
Why us?	1.Reasonable price with excellent quality 2.Abundant stock and prompt delivery 3.Rich supply and export experience, sincere service 4.Reliable forwarder, 2-hour away from port.

Standard	Description
ASTM A182/A182M	Forged or rolled alloy steel pipe flanges, forged fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASTM A403/A403M	Wrought austenitic stainless steel piping fittings.
ASTM A815/A815M	Wrought ferritic, ferritic/austenitic and martensitic stainless steel piping fittings.
AS 2129	Flanges for pipes, valves and fittings
ANSI/ASME B1.20.1	Pipe threads, general purpose (inch).
ANSI B16.5	Steel pipe flanges and flanged fittings.
ANSI B16.9	Factory-made wrought steel butt-welding fittings.
ANSI B16.11	Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings
ANSI B16.25	Butt-welding ends.
MSS SP43	Wrought stainless steel butt-welding fittings. Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
BS21	Threading.
ISO 4144	Stainless steel fittings threaded to ISO 7-1.
MSS SP-95	Swage(d) Nipples and Bull Plugs
BS3799	Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
ANSI B 16.9 ASTM A403 ASME SA403	Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
API 590-605 ASME B16.9	Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends
ASME B16.28	Wrought Steel Buttwelding Short Radius Elbows and Returns

Certified & Highly Durable

WPHY 60 carbon steel pipe nipples are engineered for strength, boasting a minimum tensile strength of 414 MPa and complying with ASTM A860 MSS SP-75 standards. Each nipple undergoes heat treatment and is coated against corrosion, making them reliable even in demanding environments.

Complete Traceability & Quality Assurance

Every pipe nipple includes clear markings indicating its size, grade, and manufacturer, ensuring traceability throughout the supply chain. Rigorous 100% hydrostatic and visual inspections further guarantee product integrity before dispatch.

Versatile End Connections & Customization

Choose from plain, beveled, or male threaded ends to suit different piping requirements. Custom lengths, diameters, and thickness options, along with compatibility for ANSI, DIN, and JIS flanges, allow for seamless integration into any project.

Reliable Protection & Packaging

Each nipple is fitted with plastic caps on ends and bundled safely to prevent transit damage. Black painted or anti-rust coatings extend product lifespan, ensuring delivery in optimal condition.

FAQ's of WPHY 60 Carbon Steel Pipe Nipples:

Q: How are WPHY 60 carbon steel pipe nipples manufactured?

A: These pipe nipples are produced using hot finished, seamless, or welded manufacturing processes. They undergo heat treatment (either normalized or quenched and tempered) to enhance their mechanical properties and durability.

Q: What types of end connections are available for these pipe nipples?

A: WPHY 60 nipples are available with plain, beveled, or male threaded ends. Threaded ends can be supplied with NPT or BSPT thread types, as per your project specifications.

Q: When should WPHY 60 nipples be used in piping systems?

A: They are recommended for use in oil, gas, petrochemical, and industrial applications where reliable high-pressure and temperature-resistant connections are required. Their robust construction and corrosion resistance make them ideal for harsh environments.

Q: Where can these pipe nipples be installed?

A: These nipples are suitable for pipelines requiring ANSI, DIN, or JIS flange compatibility and can be used globally, including in projects across India and for export markets.

Q: What inspection and quality control measures are conducted?

A: Each pipe nipple is subjected to 100% hydrostatic and visual inspection, ensuring it meets strict quality standards before being marked with size, grade, and manufacturer information.

Q: How does the corrosion resistance of these pipe nipples benefit my project?

A: Thanks to black painting or custom anti-rust coatings, WPHY 60 nipples offer enhanced corrosion resistance. This protection extends service life and reduces maintenance needs in corrosive environments.

Q: What are the main advantages of using WPHY 60 over other materials?

A: WPHY 60 offers a high yield and tensile strength, excellent pressure and temperature resistance, and customizable options for dimensions and coatings, providing a cost-effective and reliable solution for critical piping connections.
