WPHY 60 Carbon Steel Reducing Elbows

Get a Price/Quote

WPHY 60 Carbon Steel Reducing Elbows Specification

Bend Radius
Short Radius (SR) and Long Radius (LR) available

Sealing Type
Metal to Metal

Tolerance
1% or as per standard requirements

Tensile Strength
>= 60ksi (415 MPa)

Diameter
Custom as per requirement

Yield Strength
>= 60ksi (415 MPa)

Coating Type
Black Paint / Anti-rust

Connection Type
Welded

Flexibility
Rigid

Temperature Range
-20C to 600C

Product Type
Reducing Elbow

Material
WPHY 60 Carbon Steel

Connection
Butt Weld

Shape
Elbow (Reducing)

Standard
ASTM A860 / MSS-SP-75

Surface Treatment
Black Painted / Anti-rust Oil Coated

Outer Diameter
1/2 to 48 (DN15 - DN1200)

Section Shape
Round

Length
As per ASME/ANSI standards

Thickness
SCH 40, SCH 80, SCH 160, or custom

Color
Black

Usage
Pipe Fitting for Flow Direction Change

Rated Pressure
Class 150 to 2500 (as per design)

Application
Oil & Gas, Petrochemical, Power Plants, Water Supply

Material Grade
WPHY 60

Life Span
Up to 25 years under normal conditions

HS Code
73079300

Elbow Degree
22.5, 45, 90, 180

Corrosion Resistance
Good for Carbon Steel Applications

Design Code
ASME B16.9/B16.28

Availability
Ready Stock or Custom Production

Inspection
Ultrasonic, Dimensional, Visual, Hydrostatic

Packing
Wooden Cases / Pallets

End Type
Bevel End/Plain End

Compliance
NACE MR0175, ISO, API

Hardness
Max 235 HB

Manufacturing Process
Seamless or Welded

About WPHY 60 Carbon Steel Reducing Elbows

We are manufacturer of WPHY 42 Reducing Elbows and supply high quality WPHY 42 Reducing Elbows in both large and small quantities worldwide & offer you the best prices in the market.
Export packaging is geared towards the protection, handling and transport of WPHY 42 Reducing Elbows by air or sea freight and, as such, shares many characteristics with export and transport packaging. Utmost care must also be taken to make overseas packaging suitable for long periods of storage. It is important for overseas packaging to be designed with ease of handling in mind, so as to ensure WPHY 42 Reducing Elbows is treated with the utmost care at all times.
Grade Specification: Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A420 WPL6

WPHY 60 equivalent
A860 WPHY 60	A860 Grade WPHY 60 Fittings
A694 WPHY 60	A694 Grade F60 Flanges
A234 WPHY 60	A234 Grade WPB Carbon Steel Fittings A234 AISI 4130 High Strength Low Alloyed Steel Fittings

Product Name	Pipe Fittings, Buttweld Fittings, Reducer, Elbow, tee
Material	A234 WPB A105 A283-D A135-A A53-A A106-A A179-C A214-C A192 A226 A315-B A53-B A106-B A106-C A178-C A210-A-1 A210-C
Size	Size 1/4 to 48 Outside Diameter 13.7 mm to 1219 mm
Standard	ASTM/ANSI.B16.9 ASTM/ANSI B16.28 ASTM /ANSI B16.11 ASTM/ANSI B16.25 BS1965 BS1640DIN 2605 DIN2615 DIN2616 DIN2617 GB 12459-90 GB/T13401-92 GB/T21635 GB/T21634 JIS B2311 JISB2312 JISB2313 JISB2316 ISO 3419-1981 ISO5251-1981
Certificates	API5L, ISO 9001:2008,SGS, BV,CCIC
Wall thickness	SCH10, SCH20, SCH30, STD, SCH40, SCH60, SCH80, SCH100 SCH120, SCH160, XS, XXS
Surface Treatment	black paint, varnish, oil, galvanized, anti corrosion coatings
Marking	Wooden case & pallet
Pipe Ends	Under 2 inch plain end. 2 inch and above Beveled. Plastic caps (small OD) ,Iron protector (large OD)
Pipe Length	1. Single Random Length and double Random Length. 2. SRL:3M-5.8M DRL:10-11.8M or As clients requested length 3. fixed length(5.8m, 6m, 12m)
Packaging	Loose package; Packaged in bundles (2Ton Max); bundled pipes with two slings at the both end for easy loading and discharging; End with Plastic caps; wooden cases.
Test	Chemical Component Analysis, Mechanical Properties, Technical Properties, Exterior Size Inspection, hydraulic testing , X-ray Test.
Application	liquid delivery; Structure pipe; High and low pressure Boiler tube; Seamless steel tubes for petroleum cracking; oil pipe; gas pipe.
Why us?	1.Reasonable price with excellent quality 2.Abundant stock and prompt delivery 3.Rich supply and export experience, sincere service 4.Reliable forwarder, 2-hour away from port.

Standard	Description
ASTM A182/A182M	Forged or rolled alloy steel pipe flanges, forged fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASTM A403/A403M	Wrought austenitic stainless steel piping fittings.
ASTM A815/A815M	Wrought ferritic, ferritic/austenitic and martensitic stainless steel piping fittings.
AS 2129	Flanges for pipes, valves and fittings
ANSI/ASME B1.20.1	Pipe threads, general purpose (inch).
ANSI B16.5	Steel pipe flanges and flanged fittings.
ANSI B16.9	Factory-made wrought steel butt-welding fittings.
ANSI B16.11	Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings
ANSI B16.25	Butt-welding ends.
MSS SP43	Wrought stainless steel butt-welding fittings. Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
BS21	Threading.
ISO 4144	Stainless steel fittings threaded to ISO 7-1.
MSS SP-95	Swage(d) Nipples and Bull Plugs
BS3799	Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
ANSI B 16.9 ASTM A403 ASME SA403	Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
API 590-605 ASME B16.9	Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends
ASME B16.28	Wrought Steel Buttwelding Short Radius Elbows and Returns

High-Performance Material for Demanding Applications

Crafted from WPHY 60 carbon steel and complying with ASTM A860/MSS-SP-75, these elbows are ideal for environments demanding resilience and reliability. Their robust tensile and yield strengths (60ksi/415 MPa) make them suitable for high-pressure and temperature scenarios, from -20C to 600C.

Versatile Configurations and Superior Quality Assurance

Choose from seamless or welded manufacturing, a wide range of angles and thickness (SCH 40, SCH 80, SCH 160, or custom), and end types. Each elbow undergoes stringent visual, dimensional, ultrasonic, hydrostatic inspections, and hardness testing for assured performance and compliance with ASME B16.9/B16.28 design codes.

FAQ's of WPHY 60 Carbon Steel Reducing Elbows:

Q: How are WPHY 60 Carbon Steel Reducing Elbows manufactured?

A: WPHY 60 Carbon Steel Reducing Elbows are manufactured using either seamless or welded processes. The choice depends on your application requirements and specifications. All elbows conform to ASTM A860 and MSS-SP-75 standards, and undergo inspections such as ultrasonic, dimensional, and hydrostatic tests to ensure quality and reliability.

Q: What are the main benefits of using WPHY 60 reducing elbows in piping systems?

A: These elbows provide excellent strength, fatigue resistance, and durability for changing flow direction while adjusting pipe size. Their corrosion resistance, long life span (up to 25 years under normal conditions), and available surface treatments protect against environmental damage, making them suitable for varied sectors such as oil & gas, petrochemical, and power plants.

Q: When should I choose a short radius (SR) or long radius (LR) elbow?

A: Short radius elbows are ideal where space is limited and a compact installation is needed. Long radius elbows are preferred for smoother flow and reduced pressure loss, making them suitable for larger or high-flow piping systems. Both options are available as per ASME/ANSI standards and can be selected according to your system's requirements.

Q: Where can WPHY 60 elbows be applied?

A: These elbows are used globally in industries such as oil & gas, petrochemicals, power plants, and water supply systems. Their robust mechanical properties and metal-to-metal sealing make them suitable for high-pressure, high-temperature, and corrosive environments.

Q: What is the process for inspecting and ensuring the quality of these elbows?

A: After manufacturing, each elbow undergoes thorough inspection processes-ultrasonic, visual, dimensional, hydrostatic, and hardness testing. This ensures they meet specified tolerance levels (1% or as per standards), compliance programs (NACE, API, ISO), and are fit for safe operation in demanding applications.

Q: How does the surface treatment enhance the elbow's performance?

A: Surface treatments like black painting or anti-rust oil coating protect the elbows from oxidation and environmental wear, extending their operational life and maintaining integrity even in harsh industrial environments.
