WPHY 65 Carbon Steel Reducing Cross Fitting

Send Inquiry

Request To Call Back

WPHY 65 Carbon Steel Reducing Cross Fitting

Get a Price/Quote

WPHY 65 Carbon Steel Reducing Cross Fitting Specification

Yield Strength
450 MPa minimum

Connection Type
Welded

Tolerance
0.5mm

Flexibility
Rigid

Sealing Type
Metal-to-Metal

Thread Type
Not Applicable (Welded Connection)

Coating Type
Black Epoxy / Anti-Corrosion

Temperature Range
-20C to +120C

Tensile Strength
485 MPa minimum

Diameter
As per Specification

Product Type
Reducing Cross Fitting

Material
Carbon Steel

Connection
Buttweld

Shape
Cross

Standard
ASTM A860 / MSS SP-75

Surface Treatment
Black Painted / Anti-Rust Coated

Outer Diameter
1/2 to 48 (DN15 to DN1200)

Section Shape
Round

Length
Customized / Standard

Thickness
4mm - 18mm

Color
Black

Usage
Pipeline and Piping Systems

Rated Pressure
Up to 6000 Psi

Application
Oil & Gas, Petrochemical, Power Plants, Water Treatment

Material Grade
WPHY 65

End Preparation
Beveled Ends as per ASME B16.25

Inspection
100% Radiography and Ultrasonic Testing

Heat Treatment
Normalized and Tempered

Hardness
241 HB

Impact Value
As per customer requirement or standards

Feature
High Strength, Anti Corrosive

Manufacturing Process
Seamless / Welded

Marking
Standard Marking on Body

About WPHY 65 Carbon Steel Reducing Cross Fitting

Product: Buttweld Reducing Cross

Sizes: 1/2 TO 36 (SEAMLESS UPTO 24) (WELDED 8 TO 36 )

Standards: ANSI B 16.9
ASTM A403 ASME SA403 Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings API 590-605
ASME B16.9 Factory-Made Wrought Buttwelding Fittings
ASME B16.25 Buttwelding Ends
ASME B16.28 Wrought Steel Buttwelding Short Radius Elbows and Returns
MSS SP-43 Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications

Schedule: Sch 5 TO Sch XXS.

Thickness: Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.

Type: Buttweld (BW)

Grade Specification: Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A860 WPHY 42 Pipe Fittings Manufacturers

WPHY 65 equivalent
A860 WPHY 65	A860 Grade WPHY 65 Fittings
A694 WPHY 65	A694 Grade F65 Flanges
A234 WPHY 65	A234 Grade WPB Carbon Steel Fittings A234 AISI 4130 High Strength Low Alloyed Steel Fittings

Grade Specification	Carbon Steel: ASTM/ASME A234 WPB / A860 MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70 Low temperature Steel: A420 WPL3 / A420 WPL6
WPHY 65 Fittings Size	Seamless:from 1/2 to 24
WPHY 65 Fittings Size	Welded:from 24 to 96 (or as customer requirements)
WPHY 65 Fittings Degree	22.5 deg, 30deg,45 deg,90 deg,180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D,4D,5D,6D,7D-40D.
WPHY 65 Fittings Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH80., SCH100, SCH120, SCH140, SCH160, XXS
Standard	ASME B16.9, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO
Carbon Steel Material	Carbon steel (ASTM A234 WPB, A234WPC, A420 WPL6, etc)
	Stainless steel (ASTM A403 WP304, 304L, 316, 316L, 321,etc)
	Alloy steel (ASTM A234 WP12, WP11, WP22, WP5, WP9, WP91, etc)
WPHY 65 Fittings Type	Seamless / Welded / Fabricated
WPHY 65 Fittings Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
WPHY 65 Fittings Range	NB to 48 NB in Sch 10s, 40s, 80s, 160s, XXS. From 1/2 to 30 (Seamless Pipe Fittings), Form16 to 100 (Seam Pipe Fittings)
Dimensions	ANSI/ASME B16.9, B16.28, MSS-SP-43.
Applicable Standards	1-ASME B 16.9 for large Bore 2-ASME B 16.11 for small Bore (socket welded) 3-ASME B 16.25 for butt weld ends 4-ASME B 16.28 for small radius elbow
Seamless/ Welded 100% Radiography Tested

Standard	Description
ASTM A182/A182M	Forged or rolled alloy steel pipe flanges, forged fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASTM A403/A403M	Wrought austenitic stainless steel piping fittings.
ASTM A815/A815M	Wrought ferritic, ferritic/austenitic and martensitic stainless steel piping fittings.
AS 2129	Flanges for pipes, valves and fittings
ANSI/ASME B1.20.1	Pipe threads, general purpose (inch).
ANSI B16.5	Steel pipe flanges and flanged fittings.
ANSI B16.9	Factory-made wrought steel butt-welding fittings.
ANSI B16.11	Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings
ANSI B16.25	Butt-welding ends.
MSS SP43	Wrought stainless steel butt-welding fittings. Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
BS21	Threading.
ISO 4144	Stainless steel fittings threaded to ISO 7-1.
MSS SP-95	Swage(d) Nipples and Bull Plugs
BS3799	Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry
ANSI B 16.9 ASTM A403 ASME SA403	Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
API 590-605 ASME B16.9	Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends
ASME B16.28	Wrought Steel Buttwelding Short Radius Elbows and Returns

Precision Manufacturing and Quality Assurance

Each WPHY 65 Carbon Steel Reducing Cross Fitting is meticulously crafted using seamless or welded processes and normalized, tempered heat treatment to ensure mechanical stability. Comprehensive inspections, including radiography and ultrasonic testing, safeguard against structural defects and assure compliance with relevant standards and customer specifications.

Engineered for Demanding Environments

Designed to withstand intense operating conditions, the fitting offers a minimum tensile strength of 485 MPa and a yield strength of 450 MPa. Its black epoxy or anti-corrosive coatings enhance resilience in harsh settings such as oil & gas and petrochemical industries, providing a long-lasting solution for pipeline systems.

FAQs of WPHY 65 Carbon Steel Reducing Cross Fitting:

Q: How are the WPHY 65 Carbon Steel Reducing Cross Fittings manufactured?

A: These fittings are produced either seamlessly or through welded techniques, followed by normalized and tempered heat treatment to maximize strength and ductility while meeting strict ASTM A860 / MSS SP-75 quality standards.

Q: What is the recommended usage environment for this reducing cross fitting?

A: This product is best suited for oil & gas, petrochemical, power plant, and water treatment industries, where high strength, anti-corrosion, and reliable metal-to-metal sealing are essential for safe and efficient operation.

Q: When should customers specify impact value requirements?

A: Customers can specify desired impact values at the time of order placement, ensuring the product meets site-specific safety, environmental, or regulatory standards as necessary.

Q: Where can these fittings be installed in pipeline systems?

A: WPHY 65 reducing cross fittings are typically installed in main fluid transfer and distribution pipelines, especially at junctions where a single line splits into multiple lines with different diameters.

Q: What are the benefits of the black epoxy or anti-corrosion surface coating?

A: The anti-corrosion and black epoxy coatings extend the lifetime of the fitting by minimizing oxidation and enhancing resistance to harsh chemicals, making them ideal for challenging operational environments.

Q: How are these fittings inspected to ensure quality?

A: Every unit undergoes 100% radiography and ultrasonic testing to identify internal and surface flaws, guaranteeing reliable performance and adherence to customer specifications.
